Industrial Connectivity

ICS-120

2-Port RS232/422/485 Serial Device Server (1-Port 10/100BASE-TX, -10 to 60 C, Web, Telnet and SNMP management)

ICS-115A

__feature_benefit

Serial Interface One DB9 interface supports RS232, 2-wire RS485, 4-wire RS485 and RS422 operation

__feature_benefit

Asynchronous serial data rates up to 921600bps

__feature_benefit

Data mode includes VCOM, RFC2217, TCP Server, TCP Client, UDP, Remote Pair, Modbus converter server / client and Serial Telnet modes

__feature_benefit

  Ethernet Port 1-port 100BASE-FX SFP slot

__feature_benefit

  Management IPv4 and IPv6 dual stack management

__feature_benefit

Remote Management Interfaces

__feature_benefit

- IP-based Web management - Telnet console management - Windows-based VCOM utility supports searching, monitoring and configuration setting IP NTP (Network Time Protocol)

__feature_benefit

Standard TCP/IP interface and versatile operation modes

__feature_benefit

Software Protocol supports ICMP, TCP/IP, UDP, HTTP server, DHCP client, Telnet server/client

__feature_benefit

Serial Operation mode selected via management interface

__feature_benefit

Pair Connection mode for connecting two serial devices over a network

__feature_benefit

Allows a maximum of 4 hosts to be accessed as TCP client mode

__feature_benefit

Firmware upgrade via HTTP protocol

__feature_benefit

Accessible IP security control to prevent illegal users

__feature_benefit

Event notification

__feature_benefit

- Remote syslog server - SNMP trap DHCP client for IP address assignment

__feature_benefit

PLANET Smart Discovery utility automatically finds the client devices on the network

__feature_benefit

  Case and Installation Compact size for easy Installation

__feature_benefit

- Standalone -- Wall mountable or DIN-rail mounting (optional accessory) - Co-works with PLANET MC family Media Chassis (MC-700/1500) External power adaptor 5V DC, 2A max.

__feature_benefit

Supports 6000 VDC Ethernet ESD protection

__feature_benefit

-10 to 60 degrees C operating temperature

__feature_benefit

Supports extensive LED indicators for network diagnosis

__feature_benefit

Reset button for resetting to factory default

ICS-110

__feature_benefit

Serial Interface One DB9 interface supports RS232, 2-wire RS485, 4-wire RS485 and RS422 operation

__feature_benefit

Asynchronous serial data rates up to 921600bps

__feature_benefit

Data mode includes VCOM, RFC2217, TCP Server, TCP Client, UDP, Remote Pair, Modbus converter server / client and Serial Telnet modes

__feature_benefit

  Ethernet Interface 1-port 10/100BASE-TX RJ45 interface with auto MDI/MDI-X function

__feature_benefit

  Management IPv4 and IPv6 dual stack management

__feature_benefit

Remote Management Interfaces IP-based Web management

__feature_benefit

Telnet console management

__feature_benefit

Windows-based VCOM utility supports searching, monitoring and configuration setting

__feature_benefit

IP NTP (Network Time Protocol)

__feature_benefit

Standard TCP/IP interface and versatile operation modes

__feature_benefit

Software Protocol supports ICMP, TCP/IP, UDP, HTTP server, DHCP client, Telnet server/client

__feature_benefit

Serial Operation mode selected via management interface

__feature_benefit

Pair Connection mode for connecting two serial devices over a network

__feature_benefit

Allows a maximum of 4 hosts to be accessed as TCP client mode

__feature_benefit

Firmware upgrade via HTTP protocol

__feature_benefit

Accessible IP security control to prevent illegal users

__feature_benefit

Event notification Remote syslog server

__feature_benefit

SNMP trap

__feature_benefit

DHCP client for IP address assignment

__feature_benefit

PLANET Smart Discovery utility automatically finds the client devices on the netw

__feature_benefit

  Case and Installation Compact size for easy Installation Standalone -- Wall mountable or DIN-rail mounting (optional accessory)

__feature_benefit

Co-works with PLANET MC family Media Chassis (MC-700/1500)

__feature_benefit

External power adaptor 5V DC, 2A max.

__feature_benefit

Supports 6000 VDC Ethernet ESD protection 10 to 60 degrees C operating temperature

__feature_benefit

Supports extensive LED indicators for network diagnosis

__feature_benefit

Reset button for resetting to factory default

GT-806B40

10/100/1000BASE-T to 1000BASE-BX WDM Bi-directional Fiber Converter - 1550nm - 40KM

GT-806A40

10/100/1000BASE-T to 1000BASE-BX WDM Bi-directional Fiber Converter - 1310nm - 40KM

IGTP-825AT

IP67-rated Industrial 1000BASE-X SFP to 10/100/1000T 802.3at PoE+ Media Converter (24~56V power boost, -40~75 degrees C, IK10 impact protection), 3 x waterproof cable glands included

VC-231GP

1-Port 10/100/1000T 802.3at PoE+ Ethernet to VDSL2 Converter

IXT-705AT

Industrial 10G/5G/2.5G/1G/100M Copper to 10GBASE-X SFP+ Media Converter

IGUP-1205AT

Industrial 2-Port 100/1000X SFP to 1-Port 10/100/1000T 802.3bt PoE++ Media Converter ( 802.3bt Type-4, PoH, Legacy mode support, -40 to 75 C, dual 12V~56V DC power boost, PoE Usage LED)

IGTP-815AT

IP30 Compact size Industrial 100/1000BASE-X SFP to 10/100/1000BASE-T 802.3at PoE+ Media Converter (-40 to 75 C)

IGT-815AT

Industrial Compact 100/1000BASE-X to 10/100/1000BASE-T Media Converter

IGT-1205AT

Industrial 1-port 10/100/1000T to 2-port 100/1000/2500X SFP Media Converter
